Siemens HMI Type 6AV2124-0JC01-0AX0

Siemens HMI Type 6AV2124-0JC01-0AX0

Technical data

SIMATIC HMI TP900 Comfort, Comfort Panel, touch operation, 9″ widescreen TFT display, 16 million colors, PROFINET interface, MPI/PROFIBUS DP interface, 12 MB configuration memory, Windows CE 6.0, configurable from WinCC Comfort V11
General information
Product type designationTP900 Comfort
Display
Design of displayTFT
Screen diagonal9 in
Display width195 mm
Display height117 mm
Number of colors16 777 216
Resolution (pixels)
● Horizontal image resolution800 pixel
● Vertical image resolution480 pixel
Backlighting
● MTBF backlighting (at 25 °C)80 000 h
● Backlight dimmableYes; 0-100 %
Control elements
Keyboard fonts
● Function keys
— Number of function keys0
— Number of function keys with LEDs0
● Keys with LEDNo
● System keysNo
● Numeric keyboardYes; Onscreen keyboard
● alphanumeric keyboardYes; Onscreen keyboard
Touch operation
● Design as touch screenYes; Analog-resistive
