LCD Proface KCB104VG2CG-G20 is a 10.4″ diagonal CSTN-LCD display panel product from Kyocera Display Corporation (hereafter called Kyocera), with an integral CCFL backlight system, backlight driver optional, without touch screen. Based on its features, we recommend that this model be applied to Industrial etc.
Data Sheet LCD Proface KCB104VG2CG-G20 :
| Manufacturer | Kyocera | Model Name | KCB104VG2CG-G20 |
|---|---|---|---|
| Screen Size | 10.4 inch | Screen Type | LCM , CSTN-LCD |
| Pixel Number | 640(RGB)×480 (VGA) 76PPI | Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 211.2 × 158.4 (H×V) | Outline(mm) | – |
| Viewing Angle | 45/45/35/20 (Typ.)(CR≥2) | Response | 16/80 (Typ.)(Tr/Td) ms |
| Good View at | – | Work Mode | STN, Normally Black, Transmissive |
| Color Depth | Color | Backlight | 2 pcs CCFL , Optional |
| Mass | – | Used for | |
| Refresh Rate | 75Hz | Touchscreen | Without |
| Signal Type | Parallel Data (1ch, 8-bit) Connector |
Kami bergerak di bidang Mechanical-Electrical & Industrial Automation Systems. Untuk informasi harga, Penawaran dan Stok Barang, silahkan hubungi kami di bawah ini :
PT. Dutekindo Multi Kautsar
Address : Jl. Dr. Saharjo No. 86 RT/RW. 007/008
Kel. Pasar Manggis, Kec. Setiabudi, Jakarta Selatan 12960
Phone / WA : +62 859 4238 1853
